PRODUCT DESCRIPTION
Double pallets stacker Max.lift height De 1.6 metro a 2.5 metros capacity two decker pallet jack electric pallet truck
Advantages:
SAFETY AND PRODUCTIVITY:
●Carry two pallets at one single time.
●The tiller head is equipped with an emergency reverse direction switch, which provides safer operation.
●Built -in pressure relief valve protects the truck from overload, and increases the truck’s safety.
●Stepless speed control and turtle speed switch.
STRUCTURAL
● Vertical driving wheel offers small turning redius.
● Dividable and exchangeable mast.
● Adjustable floating balance wheel is resistant to wear and stable.
● Sliding rail connects the moving part of the front and rear, makes lifting and lowering stable.
EASY MAINTENANCE
●Hall-effect throttle control eliminates ware components and prolongs its use time.
●The balance wheel is detachable, convenient to maintain.
●Integral and modularized electrical system makes the maintenance of the electrical parts convenient.
SIZE INFORMATION
| Model | | CBD20S |
| Load capacity/rated load | Q(kg) | 2000 |
| Load capacity/rated load with mast lift | Q(kg) | 1000 |
| Load capacity/rated load with wheel arm lift | Q(kg) | 2000 |
| Load center distance | c(mm) | 600 |
| Load idetance,centre of drive axle to fork | x(mm) | 831 |
| Fork height,lowered | h13(mm) | 90 |
| Tyre size,front | mm | Φ250×70 |
| Tyre size,rear | mm | Φ80×70 |
| Additional wheels(dimensions) | mm | Φ127×57 |
| Wheels,number front rear(x=driven wheels) | | 1X+2/4 |
| Height,mast lowered | h1(mm) | 1082/1212/1382 |
| Max.lift height | h3(mm) | 1600/2000/2500 |
| Initial lift | h5(mm) | 120 |
| Height of tilier in drive position min./max | h14(mm) | 780/1230 |
| Overall length | l1(mm) | 1962 |
| Length to face of forks | l2(mm) | 862 |
| Overall width | b1(mm) | 775 |
| Fork dimensions | s/e/l(mm) | 60/180/1100 |
| Width overall forks | b5(mm) | 570/650 |
| Aisle width for pallets 1000×1200 crossways | Ast(mm) | 2238 |
| Aisle width for pallets 800×1200 crossways | Ast(mm) | 2288 |
| Turning radius | Wa(mm) | 1705 |
| Travel speed,laden/unladen | Km/h | 4.5/5.2 |
| Lift speed,laden/unladen | m/s | 0.03/0.04 |
| Lowering speed,laden/unladen | m/s | 0.05/0.045 |
| Battery voltagem,nominal capacity K5 | V/Ah | 24/210 |
| Battery weight | kg | 196 |
| Battery dimensions l/w/h | mm | 750x170x580 |
| Service weight(with battery) | kg | 950 |
PACKING&SHOPING
PRODUCTION SCENE
FAQ
Q1: Can Herrman provide customized products? OEM products or ODM products?
A1: Yes, Herrman can provide customized products according to your requirement. Both OEM and ODM are acceptable. We do a lot ofnon-standard products, welcome your special custom-made.
Q2: What's the specification of the chargers?
A2: Herrman have all kinds of the chargers and welcome the customers to custom-made.
Q3: How about the delivery time?
A3: Usually Herrman producing time is 15-20 working days after we receive the advanced payment. For some standard products, we have most in stock and could delivery immediately.
Q4: Can we print the LOGO on products?
A4: Yes, the OEM is available with the permission of our customers.
Q5: What is your payment term?
A5: T/T,L/C or O/A if you want any other way, please contact us.
Q6: What can I get from cooperating with Herrman?
A6: 1. Unique products, with customized service.
2. Timely production and delivery, time is money.
3. Market protection service, long term business strategy.
